Automatic Pallet Forks
From £230.00 each ex VAT From £276.00 each inc VAT
Select a item required to configure your Automatic Pallet Forks.
From £230.00 ex VAT From £276.00 inc VAT
Information
Automatic Pallet Forks, ideal for use, with an overhead crane, in situations where there is no room for fork trucks to manoeuvre. A typical example would be use in high rise developments. Fitted with adjustable forks, having height adjustment and an automatic balancing sprung head. Units are supplied complete with a pre-fitted, restraint net frame. Protection Safety Net is available as accessory. N.B. Net is not certified or designed to catch a falling load, it is deigned to withstand a partial collapse of the load.
| Type | Fork | Fork Cross | Fork Opening | Overall | Weight | Load |
| - | Length | Section | Range | Height | - | Capacity |
| - | (mm) | (mm) | (mm) | (mm) | (kg) | (kg) |
| APF 1000 | 1000 | 100 x 35 | 300 - 1000 | 1800 - 2500 | 170 | 2000 |
| APF 1200 | 1200 | 100 x 35 | 300 - 1000 | 1800 - 2500 | 190 | 2000 |
Standard Features
- Spring loaded self-balancing head
- Restraint net frame
- Ratchet strap for securing load
- Adjustable height 1200-1900 (mm)
- Adjustable fork widths
- Convenient hand hold
Optional Features
- Protection Safety Net
Place the load over the net
Insert the eyelets in the proper hooks.
Lift under safety conditions.
Weight 10 Kg.
Dimensions 1800 x 1500 x 2200H (mm)
Capacity 2000 kg.
Availability 3-5 days. FREE UK mainland delivery (excluding Highlands & Islands)
